Thermal Anti Icing System Aircraft - Anti-icing systems are applied to various parts of the aircraft. The simplest and most durable solution for anti-icing on leading edges of wings, fins, tails, air intakes, propellers, radar and all other parts where necessary.
ETIPS is the most robust, lightest and most efficient electro-thermal ice protection system available today. The design, development and production of customized ice protection systems guarantee the best performance and the highest aerodynamic properties. The use of self-regulating heating elements that can withstand an electrical load of up to 77 watts/inch2 (12 V/cm2) and do not create dangerous fire sources after damage, but continue to function, offers a new safety standard. As a result, frost protection systems -ETIPS can not only be used on metal, but are also very suitable for implementation in composite structures.
Thermal Anti Icing System Aircraft
ETIPS is suitable for all types of aircraft and is ideal for anti-icing on wing leading edges, stabilizers, air intakes, rotors, propellers and all areas where the best anti-icing performance is required.
Typical Jet Engine Oil System [49].
EMIPS is a de-icing system developed for aircraft and flying platforms that can provide very little electrical power to prevent icing or where any thermal footprint must be avoided. -EMIPS is a system that can mechanically shake off ice. The design, development and production of customized ice protection systems guarantee the best performance and the highest aerodynamic quality. Compared to conventional pneumatic systems - EMIPS has highly improved erosion resistance and has much better aerodynamic properties that improve aircraft performance. The design, development and production of customized ice protection systems guarantee the best performance and the highest aerodynamic quality
EMIPS can be designed to de-ice metal or composite wing leading edges, stabilizers, air intakes and other areas where de-icing is required and can be combined with -ETIPS if required.
Conventional de-icing boots create an aerodynamically fouled surface on the leading edge of the propeller, resulting in a permanent loss of actual aircraft performance. These faults do not apply to integrated propeller de-icing systems. Highly damage tolerant and integrated into the propeller structure, our systems guarantee improved aircraft performance with lower energy consumption.
Ice from rotor blades is a ballistic concern for: Tilted aircraft - can damage fuselage components. Motors - can cause internal damage or 'burn out' wind turbines - danger to people and animals Read more...
Results Following The Activation Of An Electro Thermal De Icing System...
Frost protection systems can be designed to be applied or implemented on a variety of forms and materials - whether composite or metal. Systems that are light, robust, easy to handle and without any aerodynamic panels.
Ice Wind Tunnel Tests Show Pitot Tube Prop Ice Accumulation In Very Short Time Without Ice Protection System - Permanently Ice Free With Ice Protection System Even In Server Freeze Conditions
Ice protection system for radomes on sensitive electronic equipment Ice protection system for radomes on sensitive electronic equipment
Over the past few years, Villinger R&D has developed commercial, flexible semiconducting polymers that can be applied as a thin layer (< 0.2 mm) to various parts and components, creating a heat-resistant layer with a surface density of approximately 150 g/m2 or less. The liner is heated electrically using an AC or DC voltage and has a positive temperature coefficient (PTC), which provides a liner that is self-limiting in temperature and will not have the harmful "hot spots" encountered with traditional resistance heaters. The resistivity of the coating can also be chemically tailored to obtain values ranging over several orders of magnitude depending on the application requirements.
Types Of Deicing Equipment, And Their Advantages And Disadvantages
The liners are extremely damage tolerant and can easily continue to work after repeated drilling. Finally, voltage can be applied across the entire surface using flexible, low-profile electrical busbars on both sides of the coated surface, enabling extremely simple wiring configurations that can be arranged in a multitude of geometries to fine-tune the desired power density.
An extremely useful feature is the use of Villinger's heat resistant coatings which have a positive temperature coefficient (PTC). In such materials, electrical resistance increases with increasing temperature. As a result, the PTC liner can be designed to reach a maximum temperature for a given input voltage, because at some point any further increase in temperature will encounter a higher electrical resistance. As a result, PTC liners are self-limiting in temperature and prevent heater failure due to the "hot spots" that can quickly develop in conventional heaters. Willinger pads also exhibit smooth, distributed heating throughout the live zone. Because Villinger liners are self-limiting in temperature, in many cases there is no need for the thermal sensor that may be required using conventional defrost inserts, further reducing system complexity. It should also be noted that Willinger designs the polymers to have only small changes in resistance with changing ambient temperature, primarily to provide sufficient resistance at lower temperatures to prevent extreme system power utilization when initially activated. .
The PTC heating features of the Villinger coatings are set to operate at low or high temperatures to reduce power consumption when initially activated (X-axis: temperature, I-axis: resistance in ohms).
Villinger heating pads have built-in PTC features, which protect them from overheating, side effects and the development of hot spots. Aircraft and engine deicing systems are generally of two designs: either remove ice after it forms, or prevent it from forming. The first type of system is called a defrost system, and the second an anti-icing system.
Pdf] Computational Methodology For Bleed Air Ice Protection System Parametric Analysis
The defrost system has two very attractive features. First, it can use different means to transfer the energy used to remove the ice. This allows consideration of mechanical (mainly pneumatic), electrical and thermal methods. Another attribute is that it is energy efficient, requiring power only intermittently when defrosting, and some mechanical designs require relatively little power overall. This is an important consideration when designing ice protection for aircraft with limited excess power.
The main disadvantage of the de-icing system is that, by default, the aircraft will operate with accumulated ice most of the time in freezing conditions. The only time it will be free of ice will be during and immediately after the defrost cycle. This requires an understanding by the designer and the pilot of what effects ice accumulation will have on aircraft performance, both before and during system operation.
Anti-icing systems change this paradigm. If used correctly, they prevent continuous ice build-up, resulting in a clean wing with no aerodynamic penalties. An anti-icing system must have a means of continuously delivering energy or chemical flux to the surface to prevent ice from binding. A typical thermal anti-icing system does this at significant energy cost. The concept is not feasible for aircraft that do not have the necessary excess energy available in all phases of flight. An exception to this is the use of chemical systems.
It is not uncommon for a system designed as an anti-icing system to initially be used as a de-icing system. For example, the manufacturer may recommend selecting the thermal wing anti-icing system when ice accumulation is detected, thereby initially bypassing the anti-icing capability. Once turned on, the system is typically left on until the icing conditions clear, allowing the anti-icing capabilities to function as intended.
Infrared De Icing Speeds Process And Reduces Cost
The selection of system design and determination of operating procedures is based on the manufacturer's understanding of the ice accumulation tolerance exhibited by the particular airfoil. For example, the ports of turbojet/turbofan engines are almost universally protected by thermal anti-icing systems. These systems are almost always used in anti-freeze mode, meaning they are turned on when they encounter visible moisture and go below the temperature threshold. This approach is due to the inlet intolerance of the ice-swallowing compressor; an imprecise defrost cycle would result in damage and/or loss of power.
Alternatively, the same aircraft may use a thermal anti-icing system to protect the wings, but the manufacturer may recommend that the system not be activated until ice accumulation is observed on some representative surface. Here, the aerodynamic penalties associated with such "pre-activation" icing are judged to be acceptable and do not pose a safety hazard.
Whenever a design uses an ice detection system as the primary and automatic mode of operation of the anti-icing system, the system becomes a de-icing system. Automatic activation means will necessarily have a system activation and deactivation threshold. This is almost universally accomplished with an ice detector, which, as the name suggests, must have some ice in it to detect it. Therefore, the system does not activate until the ice has accumulated. Once the ice is removed, the system automatically shuts down and waits for another ice detection activation before restarting. This is the defrost cycle. We and our partners use cookies to store and/or access information on the device. We and
